BMW M4 G82 (2020-2024) front passenger lumbar support/ backrest width adjustment valve block Wiring diagrams

This page contains all the electrical diagrams for the component. front passenger lumbar support/ backrest width adjustment valve block, in which he is found in the car BMW M4 G82 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram front passenger lumbar support/ backrest width adjustment valve block (1 of 2)

Wiring diagram front passenger lumbar support/ backrest width adjustment valve block for BMW M4 G82 (2020-2024)

Get access

BRN WIRE BRN/ORG WIRE DRIVER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK DRIVER'S SEAT LUMBAR SUPPORT SWITCH DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER LUMBAR SUPPORT SWITCH FRONT PASSENGER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK FRONT PASSENGER SEAT PNEUMATIC PUMP FUSE 64 FUSE 65 LEFT FOOTWELL) PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK RED WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX W/ ELECTRICAL SEAT ADJUSTMENT W/ ELECTRICAL SEAT ADJUSTMENT MODULE W/O ELECTRICAL SEAT ADJUSTMENT MODULE W/O ELECTRICAL SEAT ADJUSTMENT WHT/RED WIRE WHT/YEL WIRE

Go to component: -> Lumbar circuit, w/ backrest -> FRONT PASSENGER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK

Wiring diagram front passenger lumbar support/ backrest width adjustment valve block (2 of 2)

Wiring diagram front passenger lumbar support/ backrest width adjustment valve block for BMW M4 G82 (2020-2024)

Get access

BRN WIRE DRIVER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT SWITCH DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT SWITCH FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FUSE 64 FUSE 65 LEFT FOOTWELL) RED WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX W/ ELECTRICAL SEAT ADJUSTMENT W/ SEAT MODULE W/O ELECTRICAL SEAT ADJUSTMENT W/O SEAT MODULE WHT/RED WIRE YEL/BLU WIRE YEL/WHT WIRE

Go to component: -> Sport seats circuit, w/ lumbar -> FRONT PASSENGER LUMBAR SUPPORT/ BACKREST WIDTH ADJUSTMENT VALVE BLOCK
