BMW M4 G82 (2020-2024) exhaust gas pressure sensor gasoline particulate filter 2 Wiring diagram
This page shows the only wiring diagram for the component.exhaust gas pressure sensor gasoline particulate filter 2, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exhaust gas pressure sensor gasoline particulate filter 2 (1 of 1)
BLK/RED WIRE
BLU WIRE
BRN WIRE
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS (LEFT SIDE OF ENGINE COMPT)
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
EXHAUST GAS PRESSURE SENSOR GASOLINE PARTICULATE FILTER 2
FUSE 206
FUSE 244
FUSE 271
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
NATURAL VACUUM LEAK DETECTION
NCA WIRE
ORG/ WIRE
PRESSURE SWITCH
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
SPARK PLUG
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (6 of 7) -> EXHAUST GAS PRESSURE SENSOR GASOLINE PARTICULATE FILTER 2
