BMW M4 G82 (2020-2024) coolant level sensor Wiring diagram
This page shows the only wiring diagram for the component.coolant level sensor, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram coolant level sensor (1 of 1)
48 VOLT BATTERY
ALL ROUND VISION CAMERA
AUTOMATIC AIR RECIRCULATION CONTROL SENSOR
BRAKE FLUID LEVEL SWITCH
BRAKE LIGHT SWITCH
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
CAMERA BASED DRIVER SUPPORT SYSTEMS
CAN BUS TERMINAL RESISTOR 11
CENTER CONSOLE CONTROL CENTER
CENTER STACK LIGHTING
CENTER STACK STORAGE COMPARTMENT LIGHTING SWITCH
CLUTCH MODULE
CONVERTIBLE TOP CONTROL UNIT
COOLANT LEVEL SENSOR
DASHBOARD LIGHTING
DASHBOARD LIGHTING 2
DASHBOARD LIGHTING 3
DIAGNOSTIC SOCKET
DRIVER CAMERA SYSTEM
ELECTRICAL MACHINE ELECTRONICS
ELECTROCHROMIC INTERIOR MIRROR
ETHERNET SWITCH
FRONT CENTER ARMREST LIGHT
FRONT INTERIOR LIGHT
GRN WIRE
INSTRUMENT PANEL
LEFT FOOTWELL)
LEFT FRONT DOOR SILL LIGHT STRIP
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT VANITY MIRROR SWITCH
LEFT ILLUMINATED CARPET
LEFT REAR DOOR SILL LIGHT STRIP
NCA WIRE
OPTIONAL EQUIPMENT SYSTEM
POWER CONTROL UNIT 48 VOLTS
PREPARATION OF CONNECTOR FOR ELECTRONIC TOLL TAG
RAIN/ LIGHT/ SOLAR/ CONDENSATION SENSOR
REAR INTERIOR LIGHT
REMOTE CONTROL RECEIVER
RIGHT FRONT DOOR SILL LIGHT STRIP
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT FRONT VENTILATION GRILLE
RIGHT ILLUMINATED CARPET
ROOF FUNCTION CENTER
Go to component: -> Ground distribution circuit (7 of 7) -> COOLANT LEVEL SENSOR
