BMW M4 G82 (2020-2024) center position convertible top hall effect sensor Wiring diagram

This page shows the only wiring diagram for the component.center position convertible top hall effect sensor, which is found in the car BMW M4 G82 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram center position convertible top hall effect sensor (1 of 1)

Wiring diagram center position convertible top hall effect sensor for BMW M4 G82 (2020-2024)

Get access

BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BRN WIRE CENTER POSITION CONVERTIBLE TOP HALL EFFECT SENSOR CONVERTIBLE TOP BRACE DOWN HALL EFFECT SENSOR CONVERTIBLE TOP BRACE UP HALL EFFECT SENSOR CONVERTIBLE TOP DRIVE UNIT RELAY 2 CONVERTIBLE TOP MODULE (RIGHT SIDE OF LUGGAGE COMPT) ELECTRIC MOTOR COWL PANEL LOCK DRIVE FUSE 266 FUSE 268 GRN WIRE GRY WIRE HOT W/ NCA WIRE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLU WIRE RELAY ENERGIZED SOFT TOP STOWED HALL EFFECT SENSOR WHT WIRE YEL WIRE

Go to component: -> Convertible top circuit (1 of 3) -> CENTER POSITION CONVERTIBLE TOP HALL EFFECT SENSOR
