BMW M4 F82/F83 facelift (2017-2020) Top hifi radio circuit, w/ active sound design

ACTIVE SOUND DESIGN BLK/VIO WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPE CONVERTIBLE FUSE 123 FUSE 159 GRAN COUPE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ LEFT REAR MID-RANGE SPEAKER LEFT REAR TWEETER REAR FUSE CARRIER RED/BLU WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT REAR MID-RANGE SPEAKER RIGHT REAR TWEETER VIO/BRN WIRE VIO/RED WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/BRN WIRE BLU/RED WIRE BRN WIRE COUPE CONVERTIBLE FRONT CENTER MID-RANGE SPEAKER FRONT CENTER TWEETER GRAN COUPE GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRY/BRN WIRE GRY/RED WIRE LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT FRONT WOOFER LEFT REAR MID- RANGE SPEAKER 2 LEFT REAR TWEETER 2 MOST DATA BUS CIRCUIT RED/BLU WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT FRONT WOOFER RIGHT REAR MID- RANGE SPEAKER 2 RIGHT REAR TWEETER 2 TOP HIFI AMPLIFIER VIO/BRN WIRE VIO/RED WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE
