BMW M4 F82/F83 facelift (2017-2020) belt tens act pos Wiring diagram
This page shows the only wiring diagram for the component.belt tens act pos, which is found in the car BMW M4 F82/F83 facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram belt tens act pos (1 of 1)
AIR BAG ACT NEG
AIR BAG ACT POS
BELT TENS ACT NEG
BELT TENS ACT POS
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/RED WIRE
COMPUTER DATA LINES SYSTEM
COUPE, GRAN COUPE
CRASH SAFETY MODULE (LOWER LEFT CENTER OF DASH)
DRIVER RETRACTOR TENSIONER
DRIVER'S AIR BAG GAS GENERATORS
FRONT PASSENGER RETRACTOR TENSIONER
FRONT PASSENGER SENSOR AIR BAG GAS GENERATOR
FRONT PASSENGER'S KNEE AIR BAG GAS GENERATOR
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/VIO WIRE
GRY/YEL WIRE
LEFT FRONT BELT FORCE LIMITER GAS GENERATOR
NCA WIRE
RED WIRE
RIGHT FRONT BELT FORCE LIMITER GAS GENERATOR
STEERING COLUMN SWITCH CLUSTER
TRG ACT NEG
TRG ACT POS
VIO/GRN WIRE
VIO/WHT WIRE
W-UP TER 15
W/ REVERSIBLE ELECTROMOTIVE AUTOMATIC REELS
W/O REVERSIBLE ELECTROMOTIVE AUTOMATIC REELS
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> BELT TENS ACT POS
