BMW M3 F80 (2014-2018) passenger's electronic outer door handle module Wiring diagram
This page shows the only wiring diagram for the component.passenger's electronic outer door handle module, which is found in the car BMW M3 F80 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's electronic outer door handle module (1 of 1)
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER TRIM BACKREST LIGHTING
DRIVER'S DOOR ENTRANCE LIGHTING
DRIVER'S DOOR GROUND LIGHT
DRIVER'S ELECTRONIC OUTER DOOR HANDLE MODULE
DRIVER'S SIDE REAR COURTESY LIGHTING
FRONT ELECTRONIC MODULE
FRONT PASSENGER TRIM BACKREST LIGHTING
GRN WIRE
GRY WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT ILLUMINATION CIRCUIT
LEFT FOOTWELL)
LEFT FRONT FOOTWELL LIGHT
ORG/GRN WIRE
PASSENGER'S DOOR ENTRANCE LIGHTING
PASSENGER'S DOOR GROUND LIGHT
PASSENGER'S ELECTRONIC OUTER DOOR HANDLE MODULE
PASSENGER'S SIDE REAR COURTESY LIGHTING
REAR DRIVER'S SIDE ENTRY LIGHT
REAR PASSENGER'S SIDE ENTRY LIGHT
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RIGHT END OF DASH)
RIGHT FRONT FOOTWELL LIGHT
VIO WIRE
W/ COMFORT ACCESS
W/O COMFORT ACCESS
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> PASSENGER'S ELECTRONIC OUTER DOOR HANDLE MODULE
