BMW M3 F80 (2014-2018) light button Wiring diagram
This page shows the only wiring diagram for the component.light button, which is found in the car BMW M3 F80 (2014-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light button (1 of 1)
BLK/GRN WIRE
BLU/RED WIRE
BOOT LID/ TAILGATE LOCK
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT POWER DISTRIBUTION BOX
FUSE 153
FUSE 28
FUSE 53
FUSE 57
GLOVE COMPARTMENT LIGHT
GLOVE COMPARTMENT LIGHT SWITCH
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT)
LEFT FRONT VANITY MIRROR LIGHT
LEFT FRONT VANITY MIRROR SWITCH
LEFT READING
LIGHT
LIGHT BUTTON
LIGHT LOCATOR
LIGHTING BUTTON
LUGGAGE COMPARTMENT LIGHT
READING LIGHT
REAR ELECTRONIC MODULE
REAR FUSE HOLDER
REAR INTERIOR LIGHT
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT READING
ROOF FUNCTION CENTER
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> LIGHT BUTTON
