Trunk & fuel door release circuit for BMW M3 E90 (2007-2013)
Trunk & fuel door release circuit
BLK WIRE
BLU WIRE
BOOT LID BUTTON
BOOT LID, CENTRAL LOCKING DRIVE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH)
CENTRAL LOCKING DRIVE UNIT GLOVE COMPT
EXCEPT CONVERTIBLE
FUEL FILLER FLAP CENTER LOCKING DRIVE
FUSE 72
FUSE 73
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT REAR LID LOCK SWITCH
REAR LID RELEASE SWITCH (INTERIOR)
RIGHT REAR LID LOCK SWITCH
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
