BMW M3 E90 (2007-2013) Hifi radio circuit, convertible with cic

18 19 20 21 22 (PIN 23-26 NOT USED) 3 4 W/O COM BOX W/ COM BOX AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM DIGITAL TUNER AERIAL DIGITAL TUNER AERIAL 2 DUAL REMOTE CONTROL RECEIVER FUSE FUSE 18 FUSE 19 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT IN-BUMPER TV AERIAL LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE ODBI SOCKET ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT IN-BUMPER TV AERIAL ROOF AERIAL TCU/ULF-SBX ULF-SBX-H/ COM BOX USB PORT VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AERIAL DIVERSITY (CENTER REAR OF ROOF) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE CONVERTIBLE TOP MODULE FM AERIAL FM AERIAL 1 FM AERIAL 2 FM AERIAL 4 FUSE 15 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE SECTION ANTENNA AMPLIFIER LEFT SIDE TRIM PANEL MID-RANGE SPEAKER LEFT SUBWOOFER NCA WIRE REAR WINDOW ANTENNA AMPLIFIER REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SIDE SECTION ANTENNA AMPLIFIER RIGHT SIDE TRIM PANEL MID-RANGE SPEAKER RIGHT SUBWOOFER SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) SDARS AERIAL W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
