Car Wiring Diagrams for Power windows circuit for BMW M3 E90 (2007-2013)

BLK/BLU WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE DRIVER'S REAR SIDE POWER WINDOW MOTOR (LEFT REAR DOOR) DRIVER'S SIDE REAR POWER ELECTRONICS JUNCTION BOX EXCEPT CONVERTIBLE FUSE 41 FUSE 81 FUSE 84 FUSE 86 GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) PASSENGER'S REAR SIDE POWER WINDOW MOTOR (RIGHT REAR DOOR) PASSENGER'S SIDE REAR POWER RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE VIO WIRE WHT WIRE WHT/GRY WIRE WHT/YEL WIRE WINDOW SWITCH (SEDAN, WAGON) YEL WIRE

BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/GRY WIRE BLU/VIO WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE BRN/VIO WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S SWITCH CLUSTER DRIVER'S WINDOW MOTOR (LEFT FRONT DOOR) FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/YEL WIRE GROUND TERM 30 SIGNAL SIGNAL GROUND TRANSDUCER 2 TRANSDUCER 2 TRANSDUCER 1 GRY WIRE GRY/BLU WIRE ORG/ WIRE ORG/GRN WIRE PASSENGER'S DOOR POWER WINDOW SWITCH PASSENGER'S WINDOW MOTOR (RIGHT FRONT DOOR) RED WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE TERMINAL 30 SIG LIN BUS K-BUS SIGNAL K-BUS SIGNAL GROUND 23 45 46 47 TRANSDUCER 1 TRANSDUCER GND TRANSDUCER GND VIO WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE
