Navigation circuit, except convertible with cic & hifi radio for BMW M3 E90 (2007-2013)

0 1 2 3 4 (PIN 5-10 NOT USED) 12 13 3 11 ODBI SOCKET AERIAL DIVERSITY (CENTER REAR OF ROOF) AUX-IN CONNECTION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/ORG WIRE CAR INFORMATION COMPUTER CIC CD CHANGER (LEFT SIDE OF REAR COMPT) CENTRAL INFORMATION DISPLAY COMPUTER DATA LINES SYSTEM COUPE, SEDAN FUSE FUSE 18 FUSE 19 GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT MICROPHONE MOST-BUS CONNECTOR NCA WIRE ORG/ WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT SIDE WINDOW ANTENNA RIGHT SIDE WINDOW ANTENNA AMPLIFIER TCU/ULF-SBX-H/ ULF-SBX/ COMBOX USB PORT W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/ COMBOX W/O COMBOX WAGON WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AERIAL DIVERSITY (CENTER REAR OF ROOF) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COUPE, SEDAN, WAGON FUSE 15 GPS AERIAL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE WINDOW ANTENNA LEFT SIDE WINDOW ANTENNA AMPLIFIER LEFT SUBWOOFER NCA WIRE REAR WINDOW AERIAL (WAGON) RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SUBWOOFER ROOF ANTENNA SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE
