Driver"s memory seat circuit, convertible for BMW M3 E90 (2007-2013)
Driver"s memory seat circuit, convertible (1 of 2)
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACKREST LOCK SWITCH
DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT)
DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT)
DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT (UNDER DRIVER'S SEAT)
DRIVER'S SEAT MODULE (UNDER DRIVER'S SEAT)
FUSE
GRN WIRE
GRY/BLK WIRE
GRY/WHT WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
ORG/GRN WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
VIO WIRE
VIO/BLK WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
Driver"s memory seat circuit, convertible (2 of 2)
BLK/VIO WIRE
BLU/BLK WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE
DRIVER'S SEAT HEAD RESTRAINT ADJUSTMENT DRIVE
DRIVER'S SEAT MODULE (UNDER DRIVER'S SEAT)
DRIVER'S SIDE EASY ENTRY SWITCH
GRN/RED WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/WHT WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO/BLK WIRE
VIO/BRN WIRE
WHT/BLK WIRE
WHT/GRN WIRE
