BMW M3 E90 (2007-2013) towing hitch release drive unit Wiring diagram
This page shows the only wiring diagram for the component.towing hitch release drive unit, which is found in the car BMW M3 E90 (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram towing hitch release drive unit (1 of 1)
3.0L
AUXILIARY BRAKE LIGHT
BOOT LID BUTTON
BOOT LID, CENTRAL LOCKING DRIVE
BRN WIRE
COUPE
CRANKSHAFT BREATHER HEATING 1
DME CONTROL MODULE
ELECTRONIC DAMPER CONTROL
ELECTRONIC POWER STEERING
ENGINE ENGINE BREATHER BREATHER HEATER 3 HEATER 4
EXCEPT CONVERTIBLE
FUEL INJECTOR RELAY
HARD TOP DRIVE UNIT RELAY 1
LEFT INNER TAIL- LIGHT
LEFT LICENSE PLATE LIGHT
NCA WIRE
OIL CONDITION SENSOR
REFRIGERANT COMPRESSOR SECONDARY CONTROL AIR PUMP VALVE
RIGHT INNER TAIL LIGHT
RIGHT LICENCE PLACE LIGHT
RIGHT LICENSE PLATE LIGHT
TIRE PRESSURE CONTROL (RDC)
TOWING HITCH RELEASE
TOWING HITCH RELEASE DRIVE UNIT
TRAILER MODULE
TRAILER SOCKET
TRANSMISSION CONTROL
Go to component -> Ground distribution circuit (4 of 4) -> TOWING HITCH RELEASE DRIVE UNIT
