BMW M3 E90 (2007-2013) secondary air pump Wiring diagram
This page shows the only wiring diagram for the component.secondary air pump, which is found in the car BMW M3 E90 (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram secondary air pump (1 of 1)
ATF TEMPERATURE SENSOR
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN HI
CAN LO
CAN TERMINATING RESISTOR
DME CONTROL MODULE (RIGHT REAR OF ENGINE COMPARTMENT)
FUSE 4
FUSE 89
GRN WIRE
HOT AT ALL TIMES
NCA WIRE
NEUTRAL SENSOR
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FUSE 70
SECONDARY AIR PUMP
TRANSMISSION MAIN SHAFT RPM SENSOR
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.0l (4 of 5) -> SECONDARY AIR PUMP
