Car Wiring Diagrams for BMW M3 E90 (2007-2013)

Wiring diagram nca (71 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (71 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

BLK WIRE BLK/BLU WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE CAR ACCESS SYSTEM (UNDER LEFT COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM 6 8 9 DRIVE LOGIC SWITCH FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE 22 FUSE 65 GEAR SELECTOR SWITCH GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/YEL WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) JUNCTION BOX ELECTRONICS LEFT MULTI- FUNCTION STEERING WHEEL SWITCH BLOCK LEFT ROCKER SWITCH NCA WIRE PARKING LOCK POWER DISTRIBUTION SYSTEM RED WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT MULTI-FUNCTION STEERING WHEEL SWITCH BLOCK RIGHT ROCKER SWITCH SIDE OF DASH) STEERING COLUMN SWITCH CLUSTER TRANSMISSION CONTROL DKG VIO/BLK WIRE VIO/WHT WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/WHT WIRE

Go to component -> A/t circuit -> NCA WIRE

Wiring diagram nca (72 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (72 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

4.0L ALTERNATOR BATTERY BATTERY SENSOR (RIGHT SIDE OF REAR COMPT) BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 105 N/A GRN WIRE GRY WIRE JUMP START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) LUGGAGE WELL B+ TERMINAL POINT NCA WIRE REAR FUSE HOLDER (RIGHT SIDE OF REAR COMPT) RED WIRE STARTER VIO WIRE

Go to component -> Charging circuit -> NCA WIRE

Wiring diagram nca (73 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (73 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

AERIAL DIVERSITY (CENTER REAR OF ROOF) AMPLIFIER (LEFT SIDE OF REAR COMPT) BLK WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/ORG WIRE BRN/WHT WIRE BRN/YEL WIRE COUPE, SEDAN, WAGON FUSE 15 GPS AERIAL GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT MID-RANGE SPEAKER LEFT FRONT TWEETER LEFT REAR HI-RANGE SPEAKER LEFT SIDE WINDOW ANTENNA LEFT SIDE WINDOW ANTENNA AMPLIFIER LEFT SUBWOOFER NCA WIRE REAR WINDOW AERIAL (WAGON) RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT TWEETER RIGHT REAR HI-RANGE SPEAKER RIGHT SUBWOOFER ROOF ANTENNA SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) VIDEO MODULE (LEFT SIDE OF REAR COMPT) W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, except convertible with cic (2 of 2) -> NCA WIRE

Wiring diagram nca (74 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (74 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

AERIAL DIVERSITY (CENTER REAR OF ROOF) AUX-IN CONNE- CTION AV SOCKET BLK WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DUEL REMOTE CONTROL RECEIVER (CENTER OF REAR COMPT) FUSE 14 FUSE 18 FUSE 19 GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ TERMINAL JUNCTION BOX (UNDER RIGHT SIDE OF DASH) MOST-BUS CONNECTOR NCA WIRE ORG/GRN WIRE RAD RADIO REAR SPOILER AM/FM AERIAL (WAGON) REAR-WINDOW AERIAL RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RELAY ENERGIZED ROOF ANTENNA SAT SATELLITE RECEIVER (LEFT SIDE OF REAR COMPT) TELEPHONE RETROFIT PACKAGES CONNECTOR TELEPHONE TRANSCEIVER (CENTER OF REAR COMPT) W/ ANTENNA DIVERSITY W/ AUTOMATIC ENGINE START-STOP FUNCTION W/O AUTOMATIC ENGINE START-STOP FUNCTION W/O ANTENNA DIVERSITY WAGON COUPE, SEDAN WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Hifi radio circuit, except convertible without cic, ccc & m-ask (1 of 2) -> NCA WIRE

Wiring diagram nca (75 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (75 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

AIR BAG SIG - AIR BAG SIG + BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT POSITIONER CONTROLLER (LEFT REAR SIDE OF INTERIOR PANEL) DRIVER'S AIR BAG INFLATOR ASSEMBLIES DRIVER'S SWITCH CLUSTER FOOTWELL MODULE (UNDER LEFT SIDE OF DASH) FUSE 30 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START JUNCTION FUSE 7 BOX (UNDER RIGHT SIDE OF DASH) LEFT "B" PILLAR AIR BAG SENSOR (LEFT REAR SIDE OF INTERIOR PANEL) LEFT FRONT AIR BAG SENSOR (LEFT SIDE OF ENGINE COMPT) LEFT SEAT BELT POSITIONER MOTOR (LEFT REAR SIDE INTERIOR PANEL) MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE ORG/ WIRE ORG/GRN WIRE PASSENGER AIR BAG DEACTIVATION SWITCH (RIGHT END OF DASH, NEAR RIGHT FRONT DOOR) RED WIRE RIGHT FRONT DOOR AIR BAG SENSOR (REAR OF RIGHT FRONT DOOR) RIGHT SEAT BELT POSITIONER MOTOR (RIGHT REAR SIDE INTERIOR PANEL) SIG CAN-BUS SIG CAN-BUS STEERING COLUMN SWITCH CLUSTER WHT WIRE WHT/BLK WIRE WHT/BRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Supplemental restraints circuit, coupe with multiple restraint system (1 of 2) -> NCA WIRE

Wiring diagram nca (76 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (76 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/VIO/YEL WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CRASH SIG DIODE PANEL DRIVER'S SEAT BELT BUCKLE CONTACT DRV CASH - DRV CASH + PASS CASH + PASS CASH - LF DOOR + GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE OCCUPANCY SIG R B PILLAR SIG ORG/ WIRE ORG/GRN WIRE PASSENGER'S SEAT BELT BUCKLE CONTACT RED WIRE RIGHT "B" PILLAR AIR BAG SENSOR (RIGHT REAR SIDE OF INTERIOR PANEL) ROOF FUNCTION CONTROL CENTER SAFETY BATTERY TERMINAL GENERATOR SEAT OCCUPANCY RECOGNITION SHIELD TERMINAL R GROUND FRT PASS SIG L B PILLAR SENS TCU VIO WIRE VIO/BLU WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit, coupe with multiple restraint system (2 of 2) -> NCA WIRE

Wiring diagram nca (77 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (77 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

AIR BAG SIG - AIR BAG SIG + BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG INFLATOR ASSEMBLIES FUSE 7 BOX (UNDER RIGHT SIDE OF DASH) GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT IN ON OR START JUNCTION LEFT "B" PILLAR AIR BAG SENSOR (LEFT MIDDLE INTERIOR PANEL) LEFT FRONT AIR BAG SENSOR (LEFT SIDE OF ENGINE COMPT) LEFT FRONT DOOR AIR BAG SENSOR (FRONT OF LEFT FRONT DOOR) MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE ORG/ WIRE ORG/GRN WIRE PASSENGER AIR BAG DEACTIVATION SWITCH (RIGHT END OF DASH, NEAR RIGHT FRONT DOOR) RIGHT FRONT AIR BAG SENSOR (RIGHT SIDE OF ENGINE COMPT) RIGHT FRONT DOOR AIR BAG SENSOR (REAR OF RIGHT FRONT DOOR) RIGHT REAR SEAT BELT PRETENSIONER SIG CAN-BUS SIG CAN-BUS STEERING COLUMN SWITCH CLUSTER VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

Go to component -> Supplemental restraints circuit, except coupe with multiple restraint system (1 of 2) -> NCA WIRE

Wiring diagram nca (78 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (78 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CRASH SIG DIODE PANEL DRIVER SEAT POSITION SENSOR DRIVER'S SEAT BELT BUCKLE CONTACT GRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT REAR SEAT BELT PRETENSIONER MULTIPLE RESTRAINT SYSTEM CONTROL UNIT (REAR OF CENTER CONSOLE) NCA WIRE OCCUPANCY SIG R B PILLAR SIG ORG/ WIRE ORG/GRN WIRE PASSENGER SEAT POSITION SENSOR PASSENGER'S SEAT BELT BUCKLE CONTACT RED WIRE ROOF FUNCTION CONTROL CENTER SAFETY BATTERY TERMINAL GENNERATOR SEAT OCCUPANCY RECOGNITION TCU TERMINAL R GROUND FRT PASS SIG L B PILLAR SENS VIO WIRE VIO/BLU WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit, except coupe with multiple restraint system (2 of 2) -> NCA WIRE

Wiring diagram nca (79 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (79 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CRASH SAFETY MODULE (REAR OF CENTER CONSOLE) DRIVER'S AIR BAG INFLATOR ASSEMBLIES DRIVER'S KNEE AIR BAG INFLATOR ASSEMBLY FUSE 7 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER FUSE 53 HOT IN ON OR START LEFT ROLLOVER PROTECTION ACTUATOR NCA WIRE ORG/GRN WIRE PASSENGER'S KNEE AIR BAG INFLATOR ASSEMBLY RED WIRE RED/YEL WIRE RIGHT ROLLOVER PROTECTION ACTUATOR ROLLOVER PROTECTION CONTROLLER SIG CAN-BUS SIG CAN-BUS STEERING COLUMN SWITCH CLUSTER VIO/RED WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit, without multiple restraint system (1 of 2) -> NCA WIRE

Wiring diagram nca (80 of 82)

Wiring diagram nca for BMW M3 E90 (2007-2013) (80 of 82)

Get lifetime access to BMW M3 E90 (2007-2013)

BLK WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRY WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) CENTER ROOF FUNCTION CONTROL CRASH SAFETY MODULE (REAR OF CENTER CONSOLE) DIODE PANEL DRIVER'S SEAT BELT BUCKLE CONTACT DRIVER'S SEAT BELT TENSIONER GENERATOR (PART OF SEAT BELT BUCKLE ASSEMBLY) GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LEFT FRONT AIR BAG SENSOR (LEFT SIDE OF ENGINE COMPT) NCA WIRE OCCUPANCY SIG R B PILLAR SIG ORG/ WIRE PASSENGER'S SEAT BELT BUCKLE CONTACT RED WIRE RIGHT "B" PILLAR AIR BAG SENSOR (RIGHT MIDDLE INTERIOR PANEL) RIGHT FRONT AIR BAG SENSOR (RIGHT SIDE OF ENGINE COMPT) RIGHT FRONT DOOR AIR BAG SENSOR (REAR OF RIGHT FRONT DOOR) SAFETY BATTERY TERMINAL GENERATOR SEAT OCCUPANCY RECOGNITION TERMINAL R GROUND FRT PASS SIG L B PILLAR SENS VIO WIRE VIO/BLU WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Supplemental restraints circuit, without multiple restraint system (2 of 2) -> NCA WIRE

BMW M3 E90 (2007-2013) nca Wiring diagrams

Wiring diagram nca (71 of 82)

List of components:

Wiring diagram nca (72 of 82)

List of components:

Wiring diagram nca (73 of 82)

List of components:

Wiring diagram nca (74 of 82)

List of components:

Wiring diagram nca (75 of 82)

List of components:

Wiring diagram nca (76 of 82)

List of components:

Wiring diagram nca (77 of 82)

List of components:

Wiring diagram nca (78 of 82)

List of components:

Wiring diagram nca (79 of 82)

List of components:

Wiring diagram nca (80 of 82)

List of components:
