BMW M3 E90 (2007-2013) driver's seat heating module Wiring diagram
This page shows the only wiring diagram for the component.driver's seat heating module, which is found in the car BMW M3 E90 (2007-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat heating module (1 of 1)
AMPLIFIER
AUC SENSOR
BLK WIRE
BRN WIRE
CAR INFORMATION DISPLAY
CD AERIAL CHANGER DIVERSITY
COMBOX
DRIVER'S PARK SWITCH DISTANCE CLUSTER CONTROL (PDC)
DRIVER'S SEAT HEATING MODULE
EJECT BOX USB HUB
ELECTRONICS JUNCTION BOX
FANFARE HORN RELAY
FROM CAR ACCESS SYSTEM (DIAGRAM 3 OF 5)
FROM FUSE 49 (DIAGRAM 3 OF 5)
FROM FUSE 65 (DIAGRAM 2 OF 5)
FRONT CIGAR LIGHTER
FUSE 10
FUSE 13
FUSE 14
FUSE 15
FUSE 19
FUSE 6 FUSE 7
FUSE 60
FUSE 8
FUSE 9
GRN WIRE
GRN/YEL WIRE
GRY WIRE
LUGGAGE COMPARTMENT SOCKET OUTLET
NCA WIRE
PASSENGER'S SEAT HEATING MODULE
RADIO (W/O CIC) CAR INFORMATION COMPUTER (CIC) (W/ CIC)
REAR CENTER CONSOLE CHARGING SOCKET
REAR CENTER CONSOLE CHARGING SOCKET 2
RED WIRE
RED/YEL WIRE
ROOF FUNCTION CONTROL CENTER
TERMINAL 15 RELAY
TO BISTABLE RELAY (DIAGRAM 5 OF 5)
TO DC/DC CONVERTER (DIAGRAM 5 OF 5)
ULF
ULF- SBX-H
ULF-SBX
W/ AUTOMATIC ENGINE START-STOP FUNCTION
W/ COMBOX
W/ HIFI AMPLIFIER
W/ ULF
W/ ULF-SBX
W/ ULF-SBX-H
W/O AUTOMATIC ENGINE START-STOP FUNCTION
W/O TOP HIFI AMPLIFIER
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> DRIVER'S SEAT HEATING MODULE
