BMW M3 E90 (2007-2013) dme control unit Wiring diagrams
This page contains all the electrical diagrams for the component. dme control unit, in which he is found in the car BMW M3 E90 (2007-2013). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dme control unit (1 of 2)
1 2 3 4 5 6 STEERING ADJUST SIG STEERING ADJUST SIG STEERING ADJUST SIG
3 4 CAN-L CAN-H
6 5 SERVOTRONIC SERVOTRONIC
ACTIVE STEERING (BEHIND LEFT FRONT WHEEL)
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
CAN-BUS CAN-BUS
COMPUTER DATA LINES SYSTEM
DME CONTROL UNIT
ECO VALVE (UNDER STARTER)
ECO VLV SIG SOL VLV
ELECTRIC LOCK (UNDER VEHICLE)
FUSE 49 SIDE OF DASH)
JUNCTION BOX (UNDER RIGHT
NCA WIRE
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
STEERING GEAR
SUPPY STEERING GND
VIO/GRN WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Active power steering circuit -> DME CONTROL UNIT
Wiring diagram dme control unit (2 of 2)
AERIAL DIVERSITY (EXCEPT CONVERTIBLE)
ALTERNATOR
BATTERY
BATTERY SENSOR
BLK WIRE
BLU WIRE
CAR ACCESS SYSTEM
COMPUTER DATA LINES SYSTEM
DME CONTROL MODULE
DME CONTROL UNIT
DME RELAY
DRIVER'S SEAT HEATING MODULE (CONVERTIBLE)
DYNAMIC STABILITY CONTROL(DSC)
EDC ELECTRONIC DAMPER CONTROL
ELECTRIC CAR ACCESS COOLANT SYSTEM PUMP
ELECTRIC FAN CUT OUT RELAY
ELECTRIC VACUUM PUMP RELAY
ELECTRO- CHROMIC INTERIOR REAR VIEW MIRROR (CONVERTIBLE)
ELECTRONIC JUNCTION BOX
ELECTRONIC POWER STEERING (EPS)
FOOTWELL MODULE
FROM FUSE 74 (DIAGRAM 1 OF 5)
FUEL INJECTORS RELAY
FUEL PUMP RELAY
FUSE
FUSE 106
FUSE 108
FUSE 3
FUSE 39
FUSE 4
FUSE 50
FUSE 55
FUSE 62
FUSE 63
FUSE 67
FUSE 68
FUSE 74
FUSE 82
FUSE 84
FUSE 86 FUSE 81
FUSE FUSE 33
GEAR INDICATOR LIGHTING
GRN WIRE
GRY WIRE
HARDTOP DRIVE UNIT RELAY 1
HARDTOP DRIVE UNIT RELAY 2
HEADLIGHT WASHERS RELAY
HOLDER (RIGHT SIDE OF REAR COMPT) FUSE 101
INSTRUMENT CLUSTER CONTROL MODULE
JUMP
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LUGGAGE WELL B+ TERMINAL POINT
N/A
NCA WIRE
OBDII SOCKET
PASSENGER'S SEAT HEATING MODULE (W/O MEMORY)
REAR FUSE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
ROOF FUNCTION CONTROL CENTER
STARTER
STARTING AID TERMINAL
TERMINAL POINT
TO FUSE
TO FUSE 39 (DIAGRAM 1 OF 5)
VIO WIRE
WHT WIRE
WIPER RELAY 1
WIPER RELAY 2
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> DME CONTROL UNIT
