Radio circuit, with hifi radio without monitor for BMW M3 E46 (1999-2006)
Radio circuit, with hifi radio without monitor (1 of 2)
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER W/ ROD ANTENNA
BLK WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
CD CHANGER
EXCEPT CONVERTIBLE
FUSE
FUSE HOLDER (GLOVE BOX)
GRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN, ACC OR START
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR LIGHTS
K- BUS
NAVIGATION COMPUTER (IF EQUIPPED)
NCA WIRE
RADIO CONTROL UNIT
REAR WINDOW
RED WIRE
RED/GRN WIRE
TELEPHONE PROVISION
VIO WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/RED WIRE
Radio circuit, with hifi radio without monitor (2 of 2)
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/ORG WIRE
COUPE CONVERTIBLE
EXCEPT CONVERTIBLE
GRN WIRE
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT MID-RANGE, TWEETER SPEAKER
LEFT FRONT TWEETER SPEAKER
LEFT FRONT WOOFER SPEAKER
LEFT REAR HIGH RANGE SPEAKER
LEFT REAR SPEAKER
LR AF+ LF AF+ LF MR- LF MR+ RF MR- RF MR+
LR AF- LF AF- LR HR+ LR HR- LFT+ LFT-
RED/GRN WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT MID-RANGE, TWEETER SPEAKER
RIGHT FRONT TWEETER SPEAKER
RIGHT FRONT WOOFER SPEAKER
RIGHT REAR HIGH RANGE SPEAKER
RIGHT REAR SPEAKER
RR AF+ RF AF+ ANT RFT+ RFT- RR HR+
RR AF- RF AF-
RR HR- RFW- RFW+ RR- RR+ 31
SEDAN
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
