Car Wiring Diagrams for Heated seats circuit for BMW M3 E46 (1999-2006)

BLU WIRE BRN WIRE BRN/BLK WIRE DRIVER'S BACKREST HEATER DRIVER'S SEAT HEATER FUSE FUSE HOLDER (GLOVE BOX) GRN/VIO WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN START, RUN OR ACC INSTRUMENT CLUSTER CONTROL MODULE PASSENGER'S BACKREST HEATER PASSENGER'S BACKREST HEATER RED WIRE RED/VIO WIRE SWITCH CENTER VIO WIRE VIO/BLU WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED/YEL WIRE YEL WIRE
