Electrochromic mirror circuit for BMW M3 E46 (1999-2006)
Electrochromic mirror circuit
1 2 3 4 5 6 7 8 9 10 REVERSE SIG INFRARED REC TERM 15
BLU/RED WIRE
BLU/YEL WIRE
BRN/BLK WIRE
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS)
FUSE
FUSE HOLDER (GLOVE BOX)
GENERAL MODULE CONTROL UNIT (BEHIND GLOVE BOX)
GRN/WHT WIRE
GRY/BLK/YEL WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
RED/BLK WIRE
SECURITY
TERM 31
