Power door locks circuit for BMW M3 E46 (1999-2006)

Power door locks circuit (1 of 2)

M3 BMW E46 (1999-2006): Power door locks circuit (1 of 2)

Get access

BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLU WIRE BRN/GRY/YEL WIRE BRN/VIO WIRE CENTRAL LOCKING FUEL FILTER FLAP (RIGHT SIDE OF LUGGAGE COMPT) CENTRAL LOCKING REMOTE CONTROL CONVERTIBLE ONLY ELECTRONIC INTERIOR REAR-VIEW MIRROR FUSE HOLDER (GLOVE BOX) GENERAL MODULE CONTROL UNIT (BEHIND GLOVE BOX) GRY/BLK/YEL WIRE GRY/BRN WIRE GRY/GRN WIRE HOT AT ALL TIMES FUSE N/A 9 15 NCA WIRE RED WIRE RED/BLK WIRE SYSTEM LOCK, DRIVER'S DOOR SYSTEM LOCK, PASSENGER'S DOOR VIO WIRE W/ INFRARED REMOTE CONTROL W/ RADIO REMOTE CONTROL WHT WIRE WHT/BLK WIRE WHT/RED/YEL WIRE YEL/RED WIRE

Power door locks circuit (2 of 2)

M3 BMW E46 (1999-2006): Power door locks circuit (2 of 2)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/WHT WIRE CENTRAL LOCKING DRIVE, GLOVE BOX (CONVERTIBLE ONLY) (IN GLOVE BOX) CENTRAL LOCKING DRIVE, TRUNK LID/TAILGATE (REAR LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM COUPE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE HAZARD WARNING/ CENTRAL LOCKING SWITCH LIFT GATE LOCK SWITCH (RIGHT SIDE LUGGAGE COMPT LID) NCA WIRE RED WIRE SWITCH GLOVE BOX CENTRAL LOCKING (IN GLOVE BOX) TRUNK LID RELEASE SOLENOID SWITCH WHT WIRE WHT/BRN WIRE WHT/RED/YEL WIRE YEL WIRE YEL/RED WIRE
