Navigation circuit, without monitor for BMW M3 E46 (1999-2006)
Navigation circuit, without monitor
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 REVERSE SIG
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 TERM 30
1 2 GPS ANT GPS ANT SHLD
A/T
ABS/ASC UNIT (LEFT REAR OF ENGINE COMPT)
AF SIG ACT+ GROUND
AF SIG ACT-
AF SIG-
ANTI-LOCK BRAKES SYSTEM
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE HOLDER (GLOVE BOX)
GPS ANTENNA
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
K-BUS SIG
M/T
NAV BUS
NAVIGATION COMPUTER (LEFT SIDE OF LUGGAGE COMPT)
NCA WIRE
RADIO CONTROL UNIT
RED/GRN WIRE
SPEED SIG
W/ DSC
W/O ASC
W/O AWD W/ AWD
WHT/BLU WIRE
WHT/RED/YEL WIRE
YEL WIRE
YEL/GRN WIRE
