Passenger"s memory seat circuit, except convertible for BMW M3 E46 (1999-2006)
Passenger"s memory seat circuit, except convertible
1 2 3 LUMBAR SW -
ADJUSTMENT SWITCHES
BLK/VIO WIRE
BLK/YEL WIRE
BLU/GRY WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT MEMORY CONTROL UNIT
FUSE
FUSE HOLDER (GLOVE BOX)
GENERAL MODULE CONTROL UNIT (BEHIND GLOVE BOX)
GRN/VIO WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
ILLUM
INSTRUMENT CLUSTER CONTROL MODULE
LUMBAR SW +
PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR
PASSENGER'S SEAT FORWARD/ BACKWARD ADJUSTMENT MOTOR
PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
PASSENGER'S SEAT MEMORY CONTROL UNIT
PASSENGER'S SEAT TILT ADJUSTMENT MOTOR
PROGRAM SWITCHES (3)
RED/BRN WIRE
SEAT FWD/BACK
SEATS SYSTEM (LUMBAR CIRCUIT, IF EQUIPPED)
SET SWITCH
TERM 31 SEAT BACKREST
VIO/GRY WIRE
VIO/RED WIRE
WHT/RED/YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
