Active bodyworks circuit for BMW M3 E46 (1999-2006)
Active bodyworks circuit
AIR BAG INDICATOR
BLK/BLU WIRE
BLK/GRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CRASH ACTUATOR, LEFT (BEHIND REAR SEAT BACKREST, LEFT)
CRASH ACTUATOR, RIGHT (BEHIND REAR SEAT BACKREST, RIGHT)
FUSE
FUSE HOLDER (GLOVE BOX)
GRN WIRE
HOT IN ACCY, RUN, START
INSTRUMENT CLUSTER CONTROL MODULE
OBD SOCKET OUTLET (IN COVER OF LEFT FOOTWELL)
ROLLOVER SENSOR (BEHIND RIGHT REAR SEAT)
VIO WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/VIO WIRE
