BMW M3 E46 (1999-2006) central locking drive, trunk lid/tailgate Wiring diagram
This page shows the only wiring diagram for the component.central locking drive, trunk lid/tailgate, which is found in the car BMW M3 E46 (1999-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram central locking drive, trunk lid/tailgate (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH (NEAR STEERING COLUMN)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
CENTRAL LOCKING DRIVE, TRUNK LID/TAILGATE
DIRECTION INDICATOR/ LOW BEAM SWITCH
GENERAL MODULE CONTROL UNIT
GRN/RED WIRE
GRN/YEL WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HAZARD WARNING/ CENTRAL LOCKING SWITCH
INSTRUMENT CLUSTER CONTROL MODULE
LEFT TAILLIGHT
LICENSE PLATE LIGHTS
NCA WIRE
RED/YEL WIRE
RIGHT TAILLIGHT
VIO/YEL WIRE
WHT WIRE
YEL/RED WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> CENTRAL LOCKING DRIVE, TRUNK LID/TAILGATE
