Car Wiring Diagrams for Auxiliary cooling fan circuit for BMW M3 E36 (1992-1999)

ABOVE 2.6 BAR ABOVE 30 BAR AUTOMATIC CLIMATE CONTROL MODULE AUX- ILIARY FUSE BOX AUXILIARY FAN MOTOR BELOW 1.5 BAR BELOW 15 BAR ABOVE 18 BAR BELOW 21 BAR BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLU WIRE BLU/BLK WIRE BRN WIRE DOUBLE TEMPER- ATURE SWITCH (RIGHT FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE (DME) (RIGHT REAR OF ENGINE COMPT) EXCEPT 1996 FRONT POWER DISTRIBUTION BOX (LEFT REAR OF ENGINE COMPT) FUSE 16 FUSE 41 FUSE 48 GRN/RED WIRE GRN/VIO OR GRN/BLU WIRE GRY/VIO WIRE HIGH SPEED RELAY (IN POWER DISTRIBUTION BOX) HOT AT ALL TIMES HOT IN RUN AND START INTEGRATED HEATING- AND CLIMATE CONTROL MODULE NORMAL SPEED RELAY (IN POWER DISTRIBUTION BOX) PRESSURE SWITCH (NEAR RIGHT HEADLIGHT) RED/GRN WIRE RED/WHT WIRE
