Anti-lock brakes circuit, without traction control for BMW M3 E36 (1992-1999)
Anti-lock brakes circuit, without traction control
ABS IND.
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRAKE LIGHT SWITCH
BRN WIRE
BRN/RED WIRE
ENGINE CONTROLS SYSTEM
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FUSE
GRN WIRE
GRN/BLU/YEL WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLK/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE
HOT IN ACCY, RUN AND START
HOT IN RUN AND START FUSE
INSTRUMENT CLUSTER
LEFT FRONT ABS SPEED SENSOR
LEFT REAR ABS SPEED SENSOR
NCA WIRE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RIGHT FRONT ABS SPEED SENSOR
RIGHT REAR ABS SPEED SENSOR
VIO WIRE
WHT/GRY/YEL (OR BRN/RED) WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
