BMW M3 E36 (1992-1999) unloader relay brake light switch Wiring diagram
This page shows the only wiring diagram for the component.unloader relay brake light switch, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram unloader relay brake light switch (1 of 1)
1996 ONLY
AIRBAG SYSTEM CONTROL MODULE
ANTI- THEFT HORN
AUXILIARY FAN MOTOR
BLOWER RELAY
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CASSETTE BOX LIGHT (1996)
CENTRAL POWER WINDOW SWITCH (CONVERTIBLE)
CHILD PROTECTION CONTROL (CONSOLE)
CONVERTIBLE TOP CONTROL MODULE
CRUISE CONTROL ACTUATOR
DIMMER RIGHT FRONT AUXILIARY TURN LIGHT
DRIVER'S POWER WINDOW SWITCH
ELECTRONIC IMMOBILIZER CONTROL MODULE IGNITION SWITCH
ENGINE COOLANT LEVEL SWITCH
FRONT FOG LIGHT RELAY
HAZARD FLASHER RELAY
HEADLIGHT/ FOG LIGHT WASHER PUMP
HIGH BEAM LIGHT RELAY
INSTRUMENT CLUSTER (1997) CHIME MODULE
INSTRUMENT CLUSTER LIGHT SWITCH
INTER- MEDIATE PRESSURE SWITCH (1997)
LEFT FOG LIGHT
LEFT FRONT AUXILIARY TURN LIGHT
LEFT FRONT TURN LIGHT
LEFT HIGH BEAM LIGHT
LEFT HORN
LEFT LOW BEAM LIGHT
LEFT PARK LIGHT
LEFT POP-OUT WINDOW SWITCH
LEFT REAR DOOR (CONSOLE) POWER WINDOW SWITCH (4 DOOR)
LEFT REAR WINDOW SWITCH (4 DOOR)
LEFT WASHER JET HEATER
LOW BEAM LIGHT RELAY
OBD II CONNECTOR
PASSENGER'S POWER WINDOW SWITCH
PRESSURE SWITCH (1996)
RIGHT FOG LIGHT
RIGHT FRONT TURN LIGHT
RIGHT HIGH BEAM LIGHT
RIGHT HORN
RIGHT LOW BEAM LIGHT
RIGHT PARK LIGHT
RIGHT WASHER JET HEATER
STARTER IMMOBILIZER SWITCH (1997)
TEMPERATURE SWITCH
THROTTLE FLAP HEATER (1997)
UNLOADER RELAY BRAKE LIGHT SWITCH
WASHER FLUID LEVEL SWITCH
WASHER PUMP (1996) (CANADA)
WIPER MOTOR
WIPER RELAY (CANADA) (1997)
WIPER/ WASHER MODULE (LOW II)
WIPER/ WASHER SWITCH HORN SWITCH
Go to component -> Ground distribution circuit (1 of 5) -> UNLOADER RELAY BRAKE LIGHT SWITCH
