BMW M3 E36 (1992-1999) thermostat automatic climate control module water valve assembly Wiring diagram
This page shows the only wiring diagram for the component.thermostat automatic climate control module water valve assembly, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram thermostat automatic climate control module water valve assembly (1 of 1)
1997 OR 1996 W/O PARK VENTILATION 1996 W/ PARK VENTILATION
1997 W/ IHKA 1997 W/ HR
35 19 W/ ASC W/O ASC
ABS RELAY
ABS SLIP CONTROL MODULE ASC SWITCH
AUTOMATIC TRANSMISSION RANGE SWITCH
AUTOMATIC TRANSMISSION RANGE SWITCH PROGRAM SWITCH
AUXILIARY CONNECTOR (1996)
AUXILIARY FUSE BOX (BEHIND LEFT KICK PANEL) FUSE
BLOWER RELAY
COMBINATION SWITCH INSTRUMENT CLUSTER
COMPRESSOR CONTROL RELAY
DATA LINK CONNECTOR
FROM
FROM FRONT POWER DISTRIBUTION BOX (DIAGRAM 2 OF 5)
FROM IGNITION SWITCH
FROM IGNITION SWITCH (DIAGRAM 3 OF 5)
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT)
FUSE
GR/BLU WIRE
GR/YEL WIRE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BLU/YEL WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HIGH BEAM LIGHT RELAY
HIGH SPEED RELAY
HORN RELAY ANTI-THEFT CONTROL MODULE
INSTRUMENT CLUSTER
LIGHT SWITCH
LIGHT SWITCH SLIP CONTROL MODULE (ABS) (1996)
MIRROR CONTROL SWITCH
MULTI- FUNCTION CLOCK UNLOADER RELAY
NORMAL SPEED RELAY
PARK HEATING/ VENTILATION RELAY BOX
REAR DEFOGGER RELAY
RED WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/GRY/YEL WIRE
REVERSING LIGHT SWITCH
SERVOTRONIC CONTROL MODULE (1996)
THERMOSTAT AUTOMATIC CLIMATE CONTROL MODULE WATER VALVE ASSEMBLY
THROTTLE FLAP HEATER
W/ ASC
W/O EGS ONLY
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> THERMOSTAT AUTOMATIC CLIMATE CONTROL MODULE WATER VALVE ASSEMBLY
