BMW M3 E36 (1992-1999) reading lights Wiring diagram
This page shows the only wiring diagram for the component.reading lights, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reading lights (1 of 1)
1994 LATE PRODUCTION OTHERS
1997 4 DOOR
4 DOOR
ANTI-THEFT SYSTEM
BODY ELECTRONICS CONTROL MODULE (ZKE IV)
BRN WIRE
BRN/BLK WIRE
BRN/BLU/YEL WIRE
BRN/GRY/YEL WIRE
BRN/RED WIRE
BRN/WHT WIRE
DRIVER'S MAKEUP MIRROR LIGHT (EX. 1997)
DRIVER'S MAKEUP MIRROR SWITCH
DRIVERS DOOR JAMB SWITCH
FRONT DOME LIGHT/ MAP READING ASSEMBLY
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT)
FUSE
GLOVE BOX LIGHT SWITCH
HOT AT ALL TIMES
HOT IN ACCY, RUN AND START
LEFT REAR DOOR CONTACT
LEFT REAR DOOR JAMB SWITCH
LEFT REAR INTERIOR LIGHT
OFF
ON OFF
OTHERS
PASSENGER'S DOOR JAMB SWITCH
PASSENGER'S MAKEUP MIRROR LIGHT (EX. 1997)
PASSENGER'S MAKEUP MIRROR SWITCH
READING LIGHTS
RED/BLK WIRE
RED/WHT WIRE
RIGHT REAR DOOR CONTACT
RIGHT REAR DOOR JAMB SWITCH
RIGHT REAR INTERIOR LIGHT
TRUNK COMPARTMENT LIGHT
TRUNK LIGHT SWITCH (LEFT SIDE OF TRUNK LID)
VIO/BLK WIRE
VIO/WHT WIRE
Go to component -> Interior lights circuit (2 of 2) -> READING LIGHTS
