BMW M3 E36 (1992-1999) off open wdo auto open Wiring diagram
This page shows the only wiring diagram for the component.off open wdo auto open, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off open wdo auto open (1 of 1)
4 DOOR
AUTO CLOSE CLOSE WDO
AUTO OPEN
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CENTRAL POWER WINDOW SWITCH (CONVERTIBLE ONLY)
CLOSE OFF OPEN AUTO OPEN
COPY
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
GRN WIRE
GRN/RED WIRE
GROUND
GRY/RED WIRE
HOT AT ALL TIMES FUSE
LEFT REAR DOOR (DOOR) POWER WINDOW SWITCH (4 DOOR ONLY)
LEFT REAR WINDOW MOTOR
OFF
OFF OPEN WDO AUTO OPEN
RED WIRE
RED/VIO WIRE
RELAY MODULE (BEHIND GLOVE BOX)
RIGHT REAR DOOR (DOOR) POWER WINDOW SWITCH (4 DOOR ONLY)
RIGHT REAR WINDOW MOTOR
VIO WIRE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power windows circuit (2 of 2) -> OFF OPEN WDO AUTO OPEN
