BMW M3 E36 (1992-1999) left seat lumbar switch left seat control switch Wiring diagram
This page shows the only wiring diagram for the component.left seat lumbar switch left seat control switch, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left seat lumbar switch left seat control switch (1 of 1)
1996 CANADA
AUXILIARY FUSE BOX (BEHIND LEFT KICK PANEL)
AUXILIARY FUSE BOX (LUGGAGE COMPARTMENT)
BODY ELECTRONICS CONTROL MODULE
BODY ELECTRONICS CONTROL MODULE (ZKE IV) RIGHT HIGH BEAM LIGHT
CHECK CONTROL MODULE LEFT LOW BEAM HEADLIGHT
COMFORT RELAY (1997)
COMPRESSOR CONTROL RELAY
CONVERTIBLE TOP CONTROL MODULE (1997 328)
FROM BATTERY (DIAGRAM 1 OF 5)
FROM FUEL PUMP RELAY (DIAGRAM 1 OF 5)
FRONT FOG LIGHT RELAY
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT)
FRONT POWER DISTRIBUTION BOX (REAR LEFT SIDE OF ENGINE COMPARTMENT) FUSE
FUEL PUMP
FUSE
GRN/VIO WIRE
HEADLIGHT/ FOGLIGHT CLEANING MODULE (SPA) (1996)
HIGH BEAM LIGHT RELAY
HIGH SPEED RELAY
HIGH SPEED RELAY (318)
INSTRUMENT CLUSTER
LEFT HIGH BEAM LIGHT LEFT FOG LIGHT
LEFT SEAT LUMBAR SWITCH LEFT SEAT CONTROL SWITCH
LOW BEAM LIGHT RELAY
NOT USED
REAR FOG LIGHT SWITCH
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN/YEL WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY MODULE
RIGHT FOG LIGHT
RIGHT LOW BEAM HEADLIGHT
RIGHT SEAT CONTROL SWITCH
SECONDARY AIR PUMP RELAY
SUNROOF CONTROL ASSEMBLY
TO IGNITION SWITCH (DIAGRAM 3 OF 5)
UNLOADER RELAY
W/ CCM W/O CCM
W/O CCM W/ CCM
WHT/BLU WIRE
WHT/GRN WIRE
WIPER/ WASHER MODULE (1997)
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 5) -> LEFT SEAT LUMBAR SWITCH LEFT SEAT CONTROL SWITCH
