BMW M3 E36 (1992-1999) except 1996 Wiring diagrams
This page contains all the electrical diagrams for the component. except 1996, in which he is found in the car BMW M3 E36 (1992-1999). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram except 1996 (1 of 2)
ABOVE 2.6 BAR
ABOVE 30 BAR
AUTOMATIC CLIMATE CONTROL MODULE
AUX- ILIARY FUSE BOX
AUXILIARY FAN MOTOR
BELOW 1.5 BAR
BELOW 15 BAR ABOVE 18 BAR
BELOW 21 BAR
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
DOUBLE TEMPER- ATURE SWITCH (RIGHT FRONT OF ENGINE COMPT)
ENGINE CONTROL MODULE (DME) (RIGHT REAR OF ENGINE COMPT)
EXCEPT 1996
FRONT POWER DISTRIBUTION BOX (LEFT REAR OF ENGINE COMPT) FUSE 16
FUSE 41
FUSE 48
GRN/RED WIRE
GRN/VIO OR GRN/BLU WIRE
GRY/VIO WIRE
HIGH SPEED RELAY (IN POWER DISTRIBUTION BOX)
HOT AT ALL TIMES
HOT IN RUN AND START
INTEGRATED HEATING- AND CLIMATE CONTROL MODULE
NORMAL SPEED RELAY (IN POWER DISTRIBUTION BOX)
PRESSURE SWITCH (NEAR RIGHT HEADLIGHT)
RED/GRN WIRE
RED/WHT WIRE
Go to component -> Auxiliary cooling fan circuit -> EXCEPT 1996
Wiring diagram except 1996 (2 of 2)
A/C SYSTEM
ACTIVATE RELAY ACTIVATE RELAY
ACTIVATE VALVE CYL 4-6 KS GROUND CAMSHAFT POS
AIR PUMP (FRONT OF ENGINE COMPT)
ASC-SIG ZA ASC-SIG ZWV ASC-SIG MCR SENSOR SIGNAL
AUXILIARY FUSE BOX
BATTERY
BLK WIRE
BLK/BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
CAMSHAFT POSITION SENSOR (CYLINDER ID) (RIGHT FRONT OF ENGINE)
CAN LOW CAN HIGH BATTERY TXD
CARBON CANISTER VALVE (IN SPARE WHEEL WELL)
COMPUTER DATA LINES (1997 ONLY)
CRANKSHAFT POSITION/ RPM SENSOR (UNDER RIGHT FRONT OF CAR)
CYL 1-3
CYL 4-6
DATA LINK CONNECTOR (RIGHT REAR SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (DME) (RIGHT REAR SIDE OF ENGINE COMPT)
EVAPORATIVE EMISSION VALVE (RIGHT OF LEFT SHOCK TOWER)
EXCEPT 1996
EXHAUST GAS FLAP VALVE (LEFT REAR OF TRUNK)
FUSE
GRN WIRE
GRN/BLU WIRE
GROUND CYL 1-3 KS CYL 1-3 KS CYL 4-6 KS PROGRAM VOLT
GRY/VIO WIRE
GRY/YEL WIRE
INSTRUMENT CLUSTER SYSTEM
KNOCK SENSOR (TOP FRONT OF ENGINE)
NCA WIRE
OBD II CONNECTOR
OXYGEN SENSOR I (IN FRONT OF CATALYTIC CONVERTER)
OXYGEN SENSOR II (IN FRONT OF CATALYTIC CONVERTER)
RED WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
SECOND AIR PUMP RELAY (IN POWER DISTRIBUTION BOX)
SECOND AIR PUMP VALVE (RIGHT SIDE OF ENGINE)
SLIP CONTROL MODULE (ABS/ASC) (BEHIND GLOVE BOX)
SOLENOID VALVE (RUNNING LOSSES) (UNDER LEFT CENTER OF CAR)
TRANSMISSION CONTROL MODULE (EGS) (RIGHT REAR SIDE OF ENGINE COMPT)
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/GRY/YEL WIRE
WHT/RED/YEL WIRE
WHT/VIO WIRE
WHT/VIO/YEL WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
Go to component -> Wiring diagram engine performance 3.2l (2 of 2) -> EXCEPT 1996
