BMW M3 E36 (1992-1999) combination switch high beam switch Wiring diagram
This page shows the only wiring diagram for the component.combination switch high beam switch, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram combination switch high beam switch (1 of 1)
BLU/ YEL WIRE
BRN WIRE
CHECK CONTROL MODULE (LEFT SIDE OF DASH)
COMBINATION SWITCH HIGH BEAM SWITCH
EXCEPT 1997 USA
FLASH HIGH
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPARTMENT)
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPT.)
FUSE
GRN RED/ WIRE
GRN WIRE
GRN/ YEL WIRE
GRN/BLU WIRE
GRN/YEL WIRE
HIGH BEAM INDICATOR
HIGH BEAM LIGHT RELAY (POWER DISTRIBUTION BOX)
HOT IN RUN AND START
INSTRUMENT CLUSTER
LEFT HIGH BEAM LIGHT
LEFT LOW BEAM LIGHT
LIGHT SWITCH
LOW BEAM LIGHT RELAY (POWER DISTRIBUTION BOX)
NORMAL
NOT USED
OFF HEAD PARK
RED GRN/ WIRE
RED WIRE
RED/ WHT WIRE
RED/WHT WIRE
RIGHT HIGH BEAM LIGHT
RIGHT LOW BEAM LIGHT
W/CCM
W/O CCM
W/O CCM W/CCM
WHT RED/ WIRE
WHT WIRE
WHT/ BLU WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL BLU/ WIRE
YEL GRN/ WIRE
YEL GRY/ WIRE
YEL RED/ WIRE
YEL WIRE
YEL/GRY (OR YEL/GRN) WIRE
