BMW M3 E36 (1992-1999) 1996 canada only Wiring diagram
This page shows the only wiring diagram for the component.1996 canada only, which is found in the car BMW M3 E36 (1992-1999). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1996 canada only (1 of 1)
1996 CANADA
1996 CANADA ONLY
4 1 (2 DOOR)
BRN WIRE
EXCEPT 1996 CANADA
FOG LIGHT SWITCH
FRONT FOG LIGHT RELAY (POWER DISTRIBUTION BOX)
FRONT FOG LIGHTS INDICATOR
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPT) FUSE
FRONT POWER DISTRIBUTION BOX (LEFT REAR SIDE OF ENGINE COMPT.)
FUSE
HOT AT ALL TIMES
HOT IN RUN AND START
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER REAR FOG LIGHTS INDICATOR
LEFT FOG LIGHT
LEFT REAR FOG LIGHT
LEFT TRUNK LIGHT ASSEMBLY
LIGHT SWITCH
OFF HEAD PARK
REAR FOG LIGHT SWITCH
RED WIRE
RED YEL/ WIRE
RED/WHT WIRE
RIGHT FOG LIGHT
VIO YEL/ WIRE
YEL BLK/ WIRE
YEL BRN/ WIRE
YEL GRN/ WIRE
YEL GRY/ WIRE
YEL VIO/ WIRE
YEL/ WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Headlights circuit (2 of 2) -> 1996 CANADA ONLY
