Trunk & fuel door release circuit for BMW M2 F87 facelift (2017-2021)
Trunk & fuel door release circuit
BLK/RED WIRE
BLU/GRY WIRE
BOOT LID/ TAILGATE LOCK
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
FRONT ELECTRONIC MODULE
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 11
FUSE 161
FUSE 500
FUSE BOX
GRN/BLK WIRE
GRN/BRN WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/
HOTEL POSITION SWITCH
OUTER TAILGATE BUTTON
REAR ELECTRONIC MODULE
REAR FUSE CARRIER
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
VEHICLE INTERIOR TAILGATE BUTTON
VIO/RED WIRE
