BMW M2 F87 facelift (2017-2021) Cooling fan circuit

BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BRN WIRE CHARACTERISTIC MAP THERMOSTAT COMPUTER DATA LINES SYSTEM COOLANT TEMPERATURE SENSOR CYLINDER HEAD TEMPERATURE SENSOR DIGITAL MOTOR ELECTRONICS (LEFT REAR OF ENGINE) ELECTRIC FAN ENGINE COMPARTMENT POWER DISTRIBUTION BOX FRONT POWER DISTRIBUTION BOX FUSE 29 FUSE 33 FUSE 400 HEAT MANAGEMENT MODULE HOT AT ALL TIMES HOT W/ INTERCOOLER COOLANT PUMP POWER DISTRIBUTION SYSTEM RED WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RELAY ENERGIZED WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE

2.0L TURBO 3.0L TURBO BLK/GRN WIRE BRN WIRE COOLANT PUMP SWITCH VALVE ELECTRIC FAN CUT OUT RELAY FUSE 2 FUSE 3 FUSE 6 HOT W/ INTEGRATED SUPPLY MODULE LOW-TEMPERATURE COOLANT PUMP RED WIRE RED/GRN WIRE RED/VIO WIRE RELAY ENERGIZED TURBOCHARGER COOLANT PUMP WHT WIRE WHT/BRN WIRE
