BMW iX i20 (2021-2024) Data link connector circuit

Data link connector circuit

Car Wiring Diagrams for iX BMW i20 (2021-2024): Data link connector circuit

BASIC CENTRAL PLATFORM (BCP) BATTERY POWER DISTRIBUTION BOX BLU/YEL WIRE BRN WIRE DIAGNOSTIC SOCKET FUSE 2 FUSE 405 GRN WIRE GRN/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED RED WIRE RED/BLK WIRE WHT/BLU WIRE YEL WIRE
