Driver assistance circuit for BMW i5 G60 (2023-2024)
Driver assistance circuit
BASIC CENTRAL PLATFORM (BCP)
BRN WIRE
CLOSE RANGE RADAR SENSOR CONTROL UNIT (RSNECU)
COMPUTER DATA LINES SYSTEM
FRONT LONG RANGE RADAR SENSOR (FRSF)
FUSE 236
FUSE 241
FUSE 271
FUSE 273
FUSE 65
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRY WIRE
HOT W/
LEFT FRONT SIDE SHORT RANGE RADAR SENSOR (SRSNVL)
LEFT REAR SHORT RANGE RADAR SENSOR (HRSNL)
MEDIUM PLATFORM AUTOMATIC DRIVING FAN
RADOME HEATING
REAR POWER DISTRIBUTION BOX
RED/BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SIDE SHORT RANGE RADAR SENSOR (SRSNVR)
RIGHT REAR SHORT RANGE RADAR SENSOR (HRSNR)
WHT WIRE
WHT/BLU WIRE
WHT/RED WIRE
YEL WIRE
