Automatic a/c circuit, 2 zone for BMW i5 G60 (2023-2024)

AUTOMATIC AIR RECIRCULATION CONTROL SENSOR BASIC CENTRAL PLATFORM (BCP) BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLANT CHANGEOVER VALVE COOLANT PUMP 3 COOLANT SHUTOFF VALVE DRIVER TOUCH CONTROL BOX FUSE 170 FUSE 235 FUSE 41 FUSE 66 GRN WIRE GRN/RED WIRE GRY WIRE GRY/GRN WIRE GRY/RED WIRE HEAT PUMP CIRCUIT EXPANSION VALVE HIGH PRESSURE REFRIGERANT PRESSURE TEMPERATURE SENSOR HOT AT ALL TIMES HOT W/ INSTRUMENT PANEL TOUCH CONTROL BOX INTERIOR TEMPERATURE SENSOR LEFT FRONT POWER DISTRIBUTION BOX LOW PRESSURE REFRIGERANT PRESSURE TEMPERATURE SENSOR REAR POWER DISTRIBUTION BOX RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX VIO WIRE VIO/YEL WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE

BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/WHT WIRE COOLANT CHANGEOVER VALVE 3 COOLANT LEVEL SENSOR ELECTRIC A/C COMPRESSOR FUSE 39 FUSE 69 GRN WIRE GRN/RED WIRE GRY WIRE GRY/RED WIRE HEAT PUMP CIRCUIT TEMPERATURE SENSOR HOT AT ALL TIMES HOT W/ LEFT FOOTWELL TEMPERATURE SENSOR LEFT FRONT VENTILATION TEMPERATURE SENSOR ORG/ WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FOOTWELL TEMPERATURE SENSOR RIGHT FRONT POWER DISTRIBUTION BOX RIGHT FRONT VENTILATION TEMPERATURE SENSOR VIO/YEL WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/YEL WIRE YEL WIRE

BATTERY MANAGEMENT ELECTRONICS BLK/RED WIRE BLU/GRN WIRE BLU/GRY WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COOLANT SHUTOFF VALVE 2 EVAPORATOR TEMPERATURE SENSOR FUSE 130 FUSE 167 GRN WIRE GRN/BLU WIRE HIGH VOLTAGE BATTERY UNIT (UNDER CENTER OF VEHICLE) HOT AT ALL TIMES HOT W/ LEFT FRONT POWER DISTRIBUTION BOX NCA WIRE ORG/ WIRE PASSENGER COMPARTMENT REFRIGERANT SHUTOFF VALVE REAR COMPARTMENT BLOWER MOTOR REAR COMPARTMENT BLOWER MOTOR OUTPUT STAGE RED WIRE RED/BLU WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED WHT WIRE WHT/BRN WIRE YEL WIRE

BRN/WHT WIRE DEFROSTER FLAP MOTOR FRESH AIR/ RECIRCULATED AIR FLAP MOTOR INDIRECT VENTILATION FLAP MOTOR LEFT CENTER VENTILATION FLAP MOTOR LEFT FRONT FOOTWELL FLAP MOTOR LEFT FRONT MIXED AIR FLAP MOTOR LEFT OUTSIDE VENTILATION FLAP MOTOR ORG/ WIRE RED/BLU WIRE RED/WHT WIRE RIGHT CENTER VENTILATION FLAP MOTOR RIGHT FRONT FOOTWELL FLAP MOTOR RIGHT FRONT MIXED AIR FLAP MOTOR RIGHT OUTSIDE VENTILATION FLAP MOTOR RIGHT REAR MIXED AIR FLAP MOTOR VIO WIRE VIO/RED WIRE VIO/WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BOTTOM RADIATOR BLIND DRIVE BRN WIRE COMBINED CHARGING UNIT (CCU) COMPUTER DATA LINES SYSTEM COOLANT CHANGEOVER VALVE 2 COOLANT PUMP COOLANT PUMP 2 ELECTRIC FAN (BEHIND RADIATOR) ELECTRIC FAN CUT-OFF RELAY FUSE 150 FUSE 151 FUSE 34 FUSE 401 FUSE 64 FUSE 70 GRN/BLU WIRE HOT AT ALL TIMES HOT W/ LEFT FRONT POWER DISTRIBUTION BOX ORG/ WIRE RADIATOR OUTLET TEMPERATURE SENSOR RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX TEMPERATURE SENSOR WHT WIRE YEL/WHT WIRE
