BMW i3 I01 (2013-2017) Anti-theft & central locking circuit

BLK WIRE BLK/YEL WIRE BLU WIRE BODY DOMAIN CONTROLLER (LOWER RIGHT SIDE OF DASH) BRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER DOOR CENTRAL LOCKING BUTTON FRONT PASSENGER DOOR LOCK FUSE 3 FUSE 39 FUSE 404 FUSE 42 FUSE 7 FUSE BOX GRN WIRE GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT AT ALL TIMES INTERIOR REAR LID BUTTON ORG/ WIRE PASSENGER POWER WINDOW DRIVE POWER DISTRIBUTION BOX LIFE MODULE RED WIRE RED/BRN WIRE RED/GRN WIRE SIREN W/ TILT ALARM SENSOR VIO WIRE WHT WIRE YEL WIRE YEL/BLU WIRE

ANTI-THEFT ALARM SYSTEM IND BLK WIRE BLK/YEL WIRE BLU WIRE BOOT LID/TAILGATE LOCK BRN WIRE BRN/BLK WIRE BRN/GRN WIRE BRN/RED WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR LOCK DRIVER POWER WINDOW DRIVE DRIVER'S DOOR CENTRAL LOCKING BUTTON ELECTROCHROMIC INTERIOR REAR VIEW MIRROR GRN WIRE GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/YEL WIRE NOISE SUPPRESSOR FILTER ORG/ WIRE RED/GRN WIRE REMOTE CONTROL RECEIVER ROOF FUNCTION CENTER VIO WIRE W/ NOISE SUPPRESSOR FILTER W/O NOISE SUPPRESSOR FILTER WHT WIRE YEL WIRE YEL/BLU WIRE

BLU WIRE BONNET BUTTON BONNET CONTACT SWITCH BRN WIRE BRN/RED WIRE ENGINE COMPARTMENT LID CENTRAL LOCKING DRIVE GRN WIRE GRY/YEL WIRE LEFT REAR BOTTOM DOOR CONTACT LEFT REAR TOP DOOR CONTACT ORG/ WIRE OUTER TAILGATE PUSH BUTTON RIGHT REAR BOTTOM DOOR CONTACT RIGHT REAR TOP DOOR CONTACT VIO WIRE WHT WIRE YEL/BLU WIRE
