Front seat ventilation circuit for BMW 8 series G14/G15 facelift (2022-2024)

AIR CONDITIONING (RIGHT SIDE OF DASH) BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT MODULE DRIVER'S SEAT BACKREST FAN 1 DRIVER'S SEAT BACKREST FAN 2 DRIVER'S SEAT BACKREST FAN 3 DRIVER'S SEAT BACKREST FAN 4 DRIVER'S SEAT CUSHION FAN 1 FUSE 53 FUSE 55 GRN WIRE GRY/WHT WIRE HOT W/ TERMINAL NCA WIRE ORG/GRN WIRE RED/YEL WIRE RIGHT FRONT POWER DISTRIBUTION BOX YEL/BRN WIRE YEL/RED WIRE

BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER SEAT MODULE FRONT PASSENGER'S SEAT BACKREST FAN 1 FRONT PASSENGER'S SEAT BACKREST FAN 2 FRONT PASSENGER'S SEAT BACKREST FAN 3 FRONT PASSENGER'S SEAT BACKREST FAN 4 FRONT PASSENGER'S SEAT CUSHION FAN 1 GRY/WHT WIRE NCA WIRE RED/YEL WIRE YEL/BRN WIRE YEL/RED WIRE
