Exterior lamps circuit for BMW 8 series G14/G15 facelift (2022-2024)

AUXILIARY STOP LAMP AUXILIARY TURN SIGNAL LAMP BACKUP LAMP BACKUP LAMPS CIRCUIT BASIC VERSION BASIC VERSION HIGH VERSION BLK WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRAKE LIGHT/ TURN SIGNAL BRN (OR BRN/BLK) WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER VEHICLE EXTERIOR MIRROR DRIVER'S DOOR SWITCH BLOCK EXCEPT CONVERTIBLE FUSE 1 FUSE 504 FUSE BOX GRN/BLU WIRE GRN/GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE HIGH VERSION HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED INTERFERENCE SUPPRESSION FILTER INTERFERENCE SUPPRESSION FILTER 2 RED WIRE RED/GRN WIRE RED/YEL WIRE RIGHT INNER TAIL LIGHT STEERING COLUMN SWITCH CLUSTER TAIL LAMP YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/RED WIRE

ACCENT LIGHT AIR CONDITIONING AIR CONDITIONING SYSTEM AUDIO CONTROL PANEL BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/YEL WIRE CENTER CONSOLE CONTROL COMPUTER DATA LINES SYSTEM CORNERING LIGHT DRIVER ASSISTANCE SYSTEM OPERATING FACILITY, HAZARD WARNING SWITCH DYNAMIC STABILITY CONTROL GRN/BLU WIRE GRN/GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE LEFT FRONTAL LIGHT ELECTRONICS LEFT HEADLIGHT ORG/ WIRE ORG/GRN WIRE PARKING BRAKE BUTTON RED/GRN WIRE RIGHT FRONTAL LIGHT ELECTRONICS RIGHT HEADLIGHT SIDE LIGHTS/ DAYTIME DRIVING LIGHTS SIDE MARKER LIGHT TURN INDICATOR TURN SIGNALS/SIDE MARKER LIGHTS LED MODULE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE

AUXILIARY TURN SIGNAL LAMP BACKUP LAMP BACKUP LAMPS CIRCUIT BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT/ TURN SIGNAL BRN WIRE EXCEPT CONVERTIBLE FRONT PASSENGER VEHICLE EXTERIOR MIRROR GRN/BLU WIRE GRN/GRY WIRE GRY/BRN WIRE GRY/VIO WIRE GRY/YEL WIRE INTERFERENCE SUPPRESSION FILTER LEFT INNER TAIL- LIGHT LEFT OUTER TAIL LIGHT NUMBER PLATE LIGHT W/ REAR LID BUTTON RIGHT OUTER TAIL LIGHT TAIL LAMP YEL/BLK WIRE YEL/BRN WIRE
