BMW 8 series G14/G15 facelift (2022-2024) w/ removable thigh support Wiring diagram
This page shows the only wiring diagram for the component.w/ removable thigh support, which is found in the car BMW 8 series G14/G15 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ removable thigh support (1 of 1)
BLU/VIO WIRE
BLU/VIO/WHT (OR WHT/BLU) WIRE
BLU/VIO/WHT WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
DRIVER'S SEAT BELT BUCKLE CONTACT
DYNAMIC STABILITY CONTROL (DSC)
FRONT PASSENGER SEAT HEATING ELECTRONICS
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATER/SENSOR
FRONT PASSENGER THIGH SUPPORT HEATING
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
GRAN COUPE
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
NCA WIRE
PNK/BLU WIRE
PNK/WHT WIRE
REAR CENTER SEAT BELT BUCKLE CONTACT
REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT
REAR PASSENGER'S SIDE BELT BUCKLE CONTACT
W/ MEMORY
W/ REMOVABLE THIGH SUPPORT
W/O MEMORY
W/O REMOVABLE THIGH SUPPORT
Go to component -> Supplemental restraints circuit (2 of 4) -> W/ REMOVABLE THIGH SUPPORT
