BMW 8 series G14/G15 facelift (2022-2024) fuse 70 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 70, in which he is found in the car BMW 8 series G14/G15 facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 70 (1 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR
CRANKCASE COOLANT SHUTOFF VALVE
CRANKCASE TEMPERATURE SENSOR
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUT-OFF RELAY
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 1
FUSE 14
FUSE 2
FUSE 400
FUSE 6
FUSE 70
GRY/BLK WIRE
HEAT MANAGEMENT MODULE
HOT AT ALL TIMES
HOT W/
HOT W/ DME MAIN RELAY ENERGIZED
HOT W/ POWER SUPPLY SENSORS/ ACTUATORS RELAY ENERGIZED
HOT W/ VALVETRONIC RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT SIDE OF RADIATOR)
TOP RADIATOR BLIND DRIVE
TURBOCHARGER COOLANT PUMP
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit, w/o rear automatic climate control (5 of 5) -> FUSE 70
Wiring diagram fuse 70 (2 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR
CRANKCASE COOLANT SHUTOFF VALVE
CRANKCASE TEMPERATURE SENSOR
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUT-OFF RELAY
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 1
FUSE 14
FUSE 2
FUSE 400
FUSE 6
FUSE 70
GRY/BLK WIRE
HEAT MANAGEMENT MODULE
HOT AT ALL TIMES
HOT W/
HOT W/ DME MAIN RELAY ENERGIZED
HOT W/ POWER SUPPLY SENSORS/ ACTUATORS RELAY ENERGIZED
HOT W/ VALVETRONIC RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT SIDE OF RADIATOR)
TOP RADIATOR BLIND DRIVE
TURBOCHARGER COOLANT PUMP
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit, w/ rear automatic climate control (5 of 5) -> FUSE 70
Wiring diagram fuse 70 (3 of 6)
ALTERNATOR
AUXILIARY BATTERY
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 244
FUSE 70
FUSE BOX
GRY/BLK WIRE
HOT AT ALL TIMES
HOT W/
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
ORG/ WIRE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
STARTER MOTOR
VIO WIRE
YEL WIRE
Go to component -> Charging circuit, w/ dual storage system -> FUSE 70
Wiring diagram fuse 70 (4 of 6)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BLU/YEL WIRE
BOTTOM RADIATOR BLIND DRIVE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE SENSOR
CRANKCASE COOLANT SHUTOFF VALVE
CRANKCASE TEMPERATURE SENSOR
DIGITAL MOTOR ELECTRONICS
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUT-OFF RELAY
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 1
FUSE 14
FUSE 2
FUSE 400
FUSE 6
FUSE 70
GRY/BLK WIRE
HEAT MANAGEMENT MODULE
HOT AT ALL TIMES
HOT W/
HOT W/ DME MAIN RELAY ENERGIZED
HOT W/ POWER SUPPLY SENSORS/ ACTUATORS RELAY ENERGIZED
HOT W/ VALVETRONIC RELAY ENERGIZED
INTEGRATED SUPPLY MODULE
LOW TEMPERATURE COOLANT CIRCUIT COOLANT PUMP
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT SIDE OF RADIATOR)
TOP RADIATOR BLIND DRIVE
TURBOCHARGER COOLANT PUMP
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Cooling fan circuit -> FUSE 70
Wiring diagram fuse 70 (5 of 6)
BRN WIRE
FUSE 254
FUSE 60
FUSE 63
FUSE 70
GRAN COUPE
GRAN COUPE COUPE, CONVERTIBLE
GRN WIRE
GRN/WHT WIRE
GRY/BLK WIRE
GRY/WHT WIRE
HOT W/
LEFT FRONT TWEETER LIGHTING
LIGHT SOURCE 16
LIGHT SOURCE 3
LIGHT SOURCE 4
LIGHT SOURCE 5
LIGHT SOURCE 6
REAR DRIVER'S SIDE DOOR POCKET LIGHTING
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT MID- RANGE SPEAKER LIGHTING
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT TWEETER LIGHTING
RIGHT REAR SPEAKER LIGHTING
YEL/RED WIRE
Go to component -> Courtesy lamps circuit (5 of 7) -> FUSE 70
Wiring diagram fuse 70 (6 of 6)
BOOSTER
BOTTOM RADIATOR BLIND DRIVE
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING
COUPE CONVERTIBLE
CRASH SAFETY MODULE
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S DOOR SWITCH BLOCK
ELECTRIC FAN
ELECTRIC FAN CUT OUT RELAY
FROM FUSE 227 (DIAGRAM 6 OF 8)
FROM FUSE 66 (DIAGRAM 4 OF 8)
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FRONT PASSENGER'S DOOR POCKET LIGHTING
FUSE 217
FUSE 224
FUSE 230
FUSE 244
FUSE 67
FUSE 68
FUSE 69
FUSE 70
GRAN COUPE
HKFM
LEFT FRONT FOOTWELL LIGHT
LEFT FRONT MICROWAVE SENSOR
LEFT FRONT MID- RANGE SPEAKER LIGHTING
LEFT FRONT TWEETER LIGHTING
LEFT REAR MICROWAVE SENSOR
NATURAL VACUUM LEAK DETECTION
PASSENGER'S DOOR SEAT SWITCH CLUSTER
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
REMOTE CONTROL RECEIVER
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT MICROWAVE SENSOR
RIGHT FRONT MID- RANGE SPEAKER LIGHTING
RIGHT FRONT TWEETER LIGHTING
RIGHT REAR MICROWAVE SENSOR
SIREN W/ TILT ALARM SENSOR
SIREN, TILT SENSOR
TO AUXILIARY BATTERY (DIAGRAM 4 OF 8)
TO FUSE BOX (DIAGRAM 1 OF 8)
TO REAR POWER DISTRIBUTION BOX (DIAGRAM 3 OF 8)
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING
TOP RADIATOR BLIND DRIVE
VERTICAL DYNAMICS PLATFORM
Go to component -> Power distribution circuit (5 of 8) -> FUSE 70
