BMW 8 series G14/G15 facelift (2022-2024) fuse 263 Wiring diagram
This page shows the only wiring diagram for the component.fuse 263, which is found in the car BMW 8 series G14/G15 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 263 (1 of 1)
AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY
BRN WIRE
CONVERTIBLE TOP CONTROL UNIT
CONVERTIBLE TOP MODULE
COUPE
DME MAIN RELAY
ELECTRIC FUEL PUMP CONTROL ELECTRONICS
EXCEPT GRAN COUPE
FROM ENGINE COMPARTMENT POWER DISTRIBUTION BOX (DIAGRAM 1 OF 8)
FRONT CENTER ARMREST LIGHT
FUSE 262
FUSE 263
FUSE 264
FUSE 268
FUSE 269
FUSE 271
FUSE 273
GRY/RED WIRE
IGNITION, FUEL INJECTION RELAY
INTEGRATED SUPPLY MODULE (RIGHT REAR OF ENGINE COMPT)
LEFT CENTER STACK AMBIENT LIGHTING
LEFT CENTER STACK CONTOUR LIGHTING
LEFT SIDE SECTION CENTER CONSOLE LIGHTING
POWER SUPPLY SENSORS/ACTUATORS RELAY
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
REGULATED DIFFERENTIAL LOCK
RIGHT CENTER STACK AMBIENT LIGHTING
RIGHT CENTER STACK CONTOUR LIGHTING
RIGHT SIDE SECTION CENTER CONSOLE LIGHTING
TAILGATE LOCK
USB CHARGING SOCKET
VALVETRONIC RELAY
WIRELESS CHARGING STORAGE
Go to component -> Power distribution circuit (8 of 8) -> FUSE 263
