BMW 8 series G14/G15 facelift (2022-2024) fuse 232 Wiring diagram
This page shows the only wiring diagram for the component.fuse 232, which is found in the car BMW 8 series G14/G15 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 232 (1 of 1)
AIR CONDITIONING (RIGHT SIDE OF DASH)
BLU/GRY WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
FRONT CENTER VENTILATION GRILLE
FUSE 231
FUSE 232
FUSE 501
FUSE BOX
GRN/VIO WIRE
HEATED REAR WINDOW BAND ELIMINATION CIRCUIT 2
HOT AT ALL TIMES
LIN POWER DISTRIBUTION BOX
NCA WIRE
REAR POWER DISTRIBUTION BOX
REAR WINDOW DEFROSTER (INTEGRAL TO REAR WINDOW)
REAR WINDOW DEFROSTER REJECTOR CIRCUIT
REAR WINDOW HEATING BUTTON
REAR WINDOW HEATING RELAY
RED WIRE
RED/GRN WIRE
WHT/BLK WIRE
Go to component -> Rear defogger circuit, coupe -> FUSE 232
