BMW 8 series G14/G15 facelift (2022-2024) convertible top brace up hall effect sensor Wiring diagram
This page shows the only wiring diagram for the component.convertible top brace up hall effect sensor, which is found in the car BMW 8 series G14/G15 facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible top brace up hall effect sensor (1 of 1)
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CONVERTIBLE TOP BRACE UP HALL EFFECT SENSOR
CONVERTIBLE TOP MODULE
COWL PANEL LOCKED HALL EFFECT SENSOR
GRN/WHT WIRE
LEFT BOTTOM CONVERTIBLE TOP BRACE HALL EFFECT SENSOR
LEFT CONVERTIBLE TOP LOCKED, CLOSED HALL EFFECT SENSOR
NCA WIRE
POWER TAILGATE ACOUSTIC SENSOR
RED WIRE
RIGHT BOTTOM CONVERTIBLE TOP BRACE HALL EFFECT SENSOR
RIGHT CONVERTIBLE TOP LOCKED, CLOSED HALL EFFECT SENSOR
SOFT TOP LOCKING UNIT
SOFT TOP STOWED HALL EFFECT SENSOR
SOFT TOP UP HALL EFFECT SENSOR
VIO WIRE
WINDSHIELD PANEL UNLOCKED HALL EFFECT SENSOR
YEL WIRE
Go to component -> Power top/sunroof circuit (3 of 3) -> CONVERTIBLE TOP BRACE UP HALL EFFECT SENSOR
