BMW 8 series G14/G15 (2018-2022) front passenger's backrest fan 2 Wiring diagram
This page shows the only wiring diagram for the component.front passenger's backrest fan 2, which is found in the car BMW 8 series G14/G15 (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's backrest fan 2 (1 of 1)
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER'S BACKREST FAN 1
FRONT PASSENGER'S BACKREST FAN 2
FRONT PASSENGER'S BACKREST FAN 3
FRONT PASSENGER'S BACKREST FAN 4
FRONT PASSENGER'S SEAT CUSHION FAN 1
FRONT PASSENGER'S SEAT MODULE
GRY/WHT WIRE
NCA WIRE
RED/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Front seat ventilation circuit (2 of 2) -> FRONT PASSENGER'S BACKREST FAN 2
